Camera Performance
● Precise positioning, quiet and smooth PTZ control
By adopting high accuracy Algorithm for PTZ Control, precise location(±0.1°), it works extremely quiet and moves smoothly and very quickly to designated position.
● Real 4K UHD image
Adopt 1/2.5 inch, 8.51 megapixel HQ "Exmor R" CMOS Sensor, achieve 3840×2160 high quality image with super high resolution. Focus on meeting the need for picture fluency while ensuring the the ultra-high definition.
● Low noise and high SNR:
Adopt advanced 2D&3D noise reduce technology and low noise CMOS sensor to reduce the noise.
● Various optical zoom 12X digital zoom
● 4KP30 HDMI video output
Support 4KP30/25, 1080P60/50/30/25, 720P60/50 etc.HD video formats.
● 4KP30 USB3.0 video output
Support 4KP30/25, 1080P30/25, 720P30/25 etc.HD video formats.
● 4KP30HD network video output
Support 4KP30/25, 1080P30/25, 720P60/50etc.HD video formats.
● 255 preset positions
255 positions can be preset through serial port, including level, pitch, zoom to preset, even if the camera is powered off, the preset data can be saved.
● Multi-functional remote controller
Equipped with simple remote control, it can not only use for level, pitch and zoom control, but also can set the parameters through remote control menu.
● OSD Chinese/English menu function
Various OSD menu, feasible for remote controller to control Chinese/English OSD menu.
Camera | 10/12/20X |
Optical Zoom | 3840×2160P30/25, 1080P60/50/30/25, 720P60/50 |
Signal system | 1/2.5 inch HQ CMOS sensor, 8.51 megapixels |
Sensor | progressive |
Scanning mode | 16X |
Digital zoom | Support ultra-low illumination: 0.1Lux@F1.6(color), 0.01Lux@F1.6 (b&w) |
Minimum illumination | 1/30s~1/10000s |
Shutter speed | Indoor/Outdoor/Auto/Manual |
White balance | Yes |
BLC | 2D&3D DNR |
DNR | >52dB |
SNR | 10X lens: f = 4.7 - 94mm FoV: 55 deg * (W) - 5.5 deg * (T) |
Horizontal Fov | 12X lens: f = 4.3 - 51.6mm FoV: 70.5 deg * (W) - 5.2 deg * (T) |
Pan rotation | 20X lens: f = 4.7 - 94mm FoV: 55.4 deg * (W) - 2.9 deg * (T) |
Tilt rotation | +170° |
Pan control Speed | -30°~+90° |
Tilt control Speed | 1/s-100/s |
Al Tracking | 1s~60°/s |
Image flip | Al Monocular Humanoid Tracking |
Preset number | Support |
Position Accuracy | 9/11/1900 0:00 |
Input/Output Interface | ±0,1° |
Video | Max 4KP30 |
HDMI | Max 4KP30, UVC1.1, PTZ |
output Interface | Network protocol: IPv4, TCP, UDP, HTTP, NTP, DNS, DHCP, ARP, RTSP, RT RTCP, ONVIF, RTMP, RTMPS, VISCA OVER IP, NDI|HX(optional). |
USB | 1*, RS-232 IN, Longest distance: 30 m, VISCA/Pelco-D/Pelco-P protocol |
LAN | 1*, RS-422, Longest distance: 1200 m, VISCA/Pelco-D/Pelco-P protocol |
Communication interface | JEITA Type (DC IN 12V) HEC3800 |
Power interface | PoE:802.3af (Optional) |
General Specificati | ons |
Input voltage | AC110V-AC220V to DC12V(DC11.5-DC12.5V) |
Input current | DC12V/2A |
Working temperature | 0°C~+45°C |
Storage temperature | -10°C~+60°C |
Power consumption | 15W(MAX) |
Package size | (Length) 173 x (Width)150 x (Height)186mm |
Weight | 2.1KG(NET:1.0KG) |
