Camera Performance
Precise positioning, quiet and smooth PTZ control
By adopting high accuracy Algorithm for PTZ Control, precise location (±0.1°), it works extremely quiet and moves smoothly and very quickly to designated position.
Full HD Image
Adopt 1/2.8 inch, 2.07 megapixel HQ CMOS Sensor, achieve 1920×1080 high quality image with high resolution. Focus on meeting the need for picture fluency while ensuring the ultra-high definition.
Low noise and high SNR:
Adopt advanced 2D&3D noise reduce technology and low noise CMOS sensor to reduce the noise.
Various optical zoom 12X digital zoom
Built-in 2 MEMS Microphone. Support Al Auto-Tracking
HDMI video output
Support 1080P60/50/30/25, 720P60/50 etc. HD video output.
USB3.0 video output
Support 1080P60/50/30/25, 720P60/50/30/25 etc. HD video output.
Network video output
Support 1080P30/25, 720P60/50etc. HD video output.
255 preset positions
255 positions can be preset through serial port, including level, pitch, zoom to preset, even if the camera is powered off, the preset data can be saved.
Multi-functional remote controller
Equipped with simple remote control, it can not only use for level, pitch and zoom control, but also can set the parameters through remote control menu.
OSD Chinese/English menu function
Various OSD menu, feasible for remote controller to control Chinese/English OSD menu.
Camera |
|
Optical Zoom |
10X |
Signal system |
1080P60/50/30/25, 720P60/50 |
Sensor |
1/2.8 inch CMOS sensor, 2.07 megapixels |
Scanning mode |
Progressive |
Digital zoom |
16X |
Minimum illumination |
0.1Lux@F1.6(color), 0.01Lux@F1.6 (b&w) |
Shutter speed |
1/30s ~ 1/10000s |
White balance |
Indoor/Outdoor/Auto/Manual |
BLC |
Yes |
DNR |
2D & 3D DNR |
SNR |
≥52dB |
Horizontal Fov |
2.9° (Tele) ~ 58° (Wide) |
Pan rotation |
±170° |
Tilt rotation |
-30° ~ +90° |
Pan control Speed |
1°/s ~ 100°/s |
Tilt control Speed |
1°/s ~ 60°/s |
AI Tracking |
AI Monocular Humanoid Tracking |
Image flip |
Support |
Preset number |
255 |
Position Accuracy |
±0.1° |
Input/Output Interface |
|
HDMI |
Up to 1080P60 |
USB |
Up to 1080P60, UVC1.1, PTZ |
LAN |
IPv4, TCP, UDP, HTTP, NTP, DNS, DHCP, ARP, RTSP, RTP, RTCP, ONVIF, RTM, RTMPS, VISCA over IP, NDI |
Communication |
RS-232 IN (30m), RS-422 (1200m), VISCA/Pelco-D/Pelco-P protocol |
Power interface |
JEITA Type (DC IN 12V) HEC3800, PoE: 802.3af (Optional) |
Others |
|
Input voltage |
AC110V~AC220V to DC12V (DC11.5~DC12.5V) |
Microphone |
Built-in 2 MEMS high quality Microphone |
Input current |
DC12V/2A |
Power consumption |
15W (Max) |
Working temperature |
0°C ~ +45°C |
Storage temperature |
-10°C ~ +60°C |
Package size |
(L)173 × (W)150 × (H)186mm |
Net weight |
1.0Kg |
Gross weight |
2.1Kg |
